Mini VGA/Audio Cat 5 Extender (1280 x 1024@150m)
The VE022 Mini Cat 5 A/V Extender allows you to extend the distance between your video/audio source and display devices by as much as 150 meters, using a Cat 5e cable, providing an easy way to replace heavy and expensive VGA cables. With hot-plugging support, you can quickly add or remove the VE022 transmitter/receiver connected to the source/display device without having to power down devices.
The VE022 Mini Cat 5 A/V Extender is a compact, convenient and economical addition to your video/audio setup.
Spesification
| Function | VE022R | VE022T |
| Video Input | ||
| Interfaces | N/A | 1 x HDB-15 Male (Black) |
| Impedance | N/A | 75 Ω |
| Video Output | ||
| Interfaces | 1 x HDB-15 Female (Blue) | N/A |
| Impedance | 75 Ω | N/A |
| Video | ||
| Max. Bandwidth | 300 MHz | 300 MHz |
| Max. Resolutions / Distance | Up to 1920 x 1200@30m; 1280 x 1024@150m | Up to 1920 x 1200@30m; 1280 x 1024@150m |
| Audio | ||
| Input | N/A | 1 x Mini Stereo Jack Female (Green) |
| Output | 1 x Mini Stereo Jack Female (Green) | N/A |
| Connectors | ||
| Power | 1 x DC Jack | 1 x DC Jack |
| Power Consumption | DC5V:0.95W:4BTU/h Note: | DC5V:0.62W:3BTU/h Note: |
| Environmental | ||
| Operating Temperature | 0 – 50°C | 0 – 50°C |
| Storage Temperature | -20 – 60°C | -20 – 60°C |
| Humidity | 0 – 80% RH, Non-Condensing | 0 – 80% RH, Non-Condensing |
| Physical Properties | ||
| Housing | Metal | Metal |
| Weight | 0.05 kg ( 0.11 lb ) | 0.05 kg ( 0.11 lb ) |
| Dimensions (L x W x H) | 6.42 x 3.53 x 2.06 cm (2.53 x 1.39 x 0.81 in.) | 7.35 x 3.53 x 2.06 cm (2.89 x 1.39 x 0.81 in.) |
| Carton Lot | 20 pcs | 20 pcs |
| Note | For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format. | |
