BEACON BE-201H 2-port HDMI KVM Switch

BEACON BE-201H 2-port HDMI KVM Switch

BE-201H is a 2-port HDMI KVM switch that allows users to control two HDMI-enabled computers using a single keyboard, mouse, monitor, and USB 2.0 devices, with added support for external audio and microphone input/output. Simple, plug-and-play design with flexible switching options.

Follow

Share

Facebook
Twitter
LinkedIn

The BE-201H is an economical and compact 2-port HDMI KVM switch that provides users with the ability to control two computers through a single console interface consisting of an HDMI monitor, USB mouse, USB keyboard, and audio and microphone devices.

Equipped with:
  • HDMI enabled video switching for sharing high-definition displays
  • USB 2.0 hub for connecting peripherals to workstations and devices.
  • Specific audio and microphone jacks for complete control of multimedia peripherals.

This solution provides an efficient and organized workspace for users, improving productivity, therefore, is excellent for home offices, expand control rooms and operator workstations that require fast toggling between two systems.

Recommended Applications
  • Desktop workstation switching
  • Control room dual-system setups
  • AV/IT maintenance consoles
  • KVM switching in classrooms or offices
  • Touchscreen display + PC control environments
  • Sharing a common Keyboard, Mouse, Speaker/Microphone and Monitor as
    well as USB 2.0 devices for 2 PCs with HDMI outputs.
  • Support HDMI resolutions: 4K@60, 1920×1200@60, 1080p …
  • Console built with USB 2.0 HUB to support devices such Touch, Storage, …
  • Console support EDID learning feature.
  • Support Port Switching via front panel SELECT button & keyboard hotkeys.
  • Support Port Switching via RS-232 (Optional).
  • Support external 3.5mm Audio and Microphone.
  • Support Online and Select status LED indicators.
  • Front panel SELECT Button Extension Cable support.
  • Hot pluggable, no software or drivers required.
